TIG WELDERS
Professional TIG Welding Machines
A full range of TIG Welders for every use and situation. Most of the power sources are developed with PFC technology and Multivoltage system to guarantee greater efficiency and lower power consumption and the use in any ambient – indoor, external, off shore.
Strength, reliability and excellent welding performances, all in an innovative and attractive design.
The TIG process uses the heat generated by an electric arc and tungsten-based electrode.
As general advantages of TIG process we can determine some points in favor:
- It is cleaner than the Stick Electrode
- Better quality welding can be achieved than other processes
- Welding generates almost no smoke
For a better view of the following sheet, please rotate your device.
Model | Input Voltage | Duty Cycle 60% | Duty Cycle 100% | Current Range | Net Weight | Dimensions | |
V | A | A | A | KG | CM | ||
PIPE270 MULTI | 110/460 | 225 | 175 | 10/270 | 24,5 | 62x24x42 | |
200 AC/DC PULSE | 90/275 | 200-140 | 155-110 | 5/200 | 19 | 62x24x42 | |
200 DC | 230 | 125-115 | 100-90 | 10/200 | 8 | 52x18x30 | |
200 DC PULSE | 110/230 | 180-130 | 145-100 | 5/200 | 11 | 52x18x30 | |
250 DC PULSE | 400 | 250-165 | 200-125 | 5/250 | 19,5 | 52x28x46 | |
400 DC PULSE | 400 | 305 | 240 | 5/400 | 26 | 59x28x46 | |
400 AC/DC PULSE | 400 | 400 | 310 | 10/400 | 29 | 64x28x46 |
What's Next Step?
Download the Complete Catalog right now and see all the solutions for welding applications available for your needs.
Get a Quote Now FOR FREE
GET A QUOTE for your new TIG Welding Machine GRAND TIG right now!
